Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity

Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity

Large Image :  Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity

Product Details:
Place of Origin: Shandong
Brand Name: Shuangyi
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: $1,500.00/pieces 2-4 pieces
Contact Now

Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity

Description
Type: Axial Flow Fan Applicable Industries: Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Home Use, Retail, Printing Shops, Construction Works , Energy & Mining
Customized Support: OEM Electric Current Type: AC
Mounting: FREE STANDING Blade Material: Stainless Steel
Warranty: 1 Year After-sales Service Provided: Free Spare Parts
Core Components: Motor, Other Cooling Type: Counter Flow
Power: 3KW-180KW Voltage: 220V/240V/380V/480V
Material: FRP Fan Diameter: 1800mm-6000mm
Air Capacity: 49800-507500m3/h Dead Weight: 943-10200kg
Turning Weight: 3034kg-36040kg Key Words: Cross Cooling Circuict Tower
Shape: Round Square

Details Images
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 0
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 1
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 2
Product Paramenters
Model No.
RotatingSpeed r/min
Air Flow m3/h
Total Pressure Pa
Motor Power  kw
2.8
2900
2662
148
0.18
2.8
1450
1331
37
0.25
3.15
1450
1895
47
0.04
3.15
2900
3790
188
0.37
3.55
2900
5424
240
0.55
3.55
1450
2712
60
0.09
4
2900
7758
304
1.1
4
1450
3879
76
0.18
4.5
1450
5524
96
0.25
5
1450
7577
119
0.37
5
960
5104
47
0.18
5.5
1450
10645
149
0.75
5.5
960
7171
59
0.37
6
1450
15157
189
1.5
6
960
10210
75
0.37
Product packaging
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 3
Customer Photos
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 4
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 5
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 6
Exhibition
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 7
Company Profile
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 8
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 9
Axial Flow Fans with 220V/240V/380V/480V Voltage and 49800-507500m3/h Air Capacity 10
FAQ
1. Q: Are you Trading Company or Manufacturing Factory?
A: We are both manufacturer trading and company. We have our own factory for almost seven years, and we have better service of overseas customers. Welcome to send your inquiry!

2. Q: I am interested in your products, could I get sample for free?
A: We can supply a few pieces FREE samples if we have some in stock, and you only need to pay the freight cost by yourself.
Welcome to send your inquiry for FREE samples!

3.Q: How about the Delivery time?
A: 10-15days after receiving the deposit based on the MOQ. Normally, 30-35days to finish the order for a 20ft container. Welcome to ask for the detailed delivery time according to your order quantity!
4. Q: How can you guarantee the product quality?
A: We have the quality control system ISO9001:2015, and it's been followed strictly. We also have the professional QC team,and each our package worker will be in charge of the final inspection according to the QC instruction before packing.

5. Q: What is about the payment terms.
A: Basically, the payment terms are T/T, L/C at sight. Western Union, Alipay.

6. Q: Can you do OEM for me?
A: We accept all OEM orders,just contact us and give me your design,we will offer you a reasonable price ASAP.

Purchasing Notes
1. If you knows little but only the volume or area of your warehouse, plant or workshop, like their length, width, height, please make sure that contact us in time. By doing so, our engineers can design the specifications and quantity of the product in your need.

2.If there is no specification parameter that required in the parameter table, please tell us your requirements and we will give you a satisfactory designing scheme.

3.If you have confirmed our products, please place an order and then make payment. After that, we will arrange delivery as soon as possible. Without change in the order before our delivery, we will give you an exquisitely prepared present. In case of refund,we have to charge 10% of the total amount as penalty.

4.If there is any difficulty in transportation, please contact us immediately and we will give you a satisfactory plan to save
freight as much as possible.
