Brief Introduction
1. Good looking:The fan body be stamp by precise mould with Power coating;
2.Centrifugal axial fan with backward curved impeller;
3.Compact structure,various size for option,easy for installation;
4.Using standard size for the inlet and outlet,it coule be connect with tubing directely;
5.Using extenal rotor motor,extremely low noise.
6.Application:Where needs air ventilation,such as Hotel,Meeting room,Restaurant,Station,Supermarket,Airport,ect...
7.Durable external rotor motor with thermal link,Matching speed-controllers is available
8.The housing can be galvanized or epoxy coated,reliable, excellent quality and maintenance free.
Inline Fans are simply the best centrifugal fans available on the market, setting the standard for performance. Centrifugal inline fan has every feature you need: compact, quiet, easy installation.
CHOSEN Centrifugal Inline Fans are widely used in agricultural indoor growing (greenhouse), specially apply in duct air ventilation in hydroponics & garden.
Also these fans are widely applied in industrial and home duct ventilation, specially in warehouse/ basement...
|
Model
|
CDF100
|
CDF125
|
CDF150
|
CDF160
|
CDF200
|
CDF250
|
CDF315
|
|
Flow rate (m3 /h)
|
400
|
410
|
700
|
800
|
1100
|
1200
|
1800
|
|
Pressure
(Pa)
|
320
|
310
|
380
|
410
|
580
|
560
|
700
|
|
Weight (KG)
|
3.4
|
3.5
|
4.8
|
4.9
|
6.5
|
6.7
|
8.2
|
