Industrial Roof Extractor Fan Without Electricity
Roof Ventilation Fan,Wind-driven Turbine Ventilator,Non Power Turbo Fan for Warehouse/Factory/Workshop :
Specifications / structure
1.Material: made of stainless steel by stretching forming, attractive appearance, no rust,
2. Bearing: wholel sealing bearing, which can ensure it operates smoothly and constantly.
3. Special central shaft design, high-class lubricating bearing system: preventing turbine blades
rotating at high speed from deformation, and extending the service life.
4, Inside support frame: cast iron.
Roof Ventilation Fan,Wind-driven Turbine Ventilator,Non Power Turbo Fan for Warehouse/Factory/Workshop :
Advantages
1, Automatically running. wind drive. One time investment, no anymore cost.
2. No operating cost, no electricity consumption, environmental protection, energy-saving.
3. No need maintenance, long life working.
4. Light weight, strong and durable construction.
5. Weather resistance, self-cleanness, high revolving sensitivity and high air venting efficiency.
6. Easy installation:.installation position: flat roof, pitched roof, concrete roof and contour plate of various industrial plants.
7, waterproof efficiency may reach 100%.
Roof Ventilation Fan,Wind-driven Turbine Ventilator,Non Power Turbo Fan for Warehouse/Factory/Workshop :
Function:
1) Exhausting turbid, humid hot air to exterior and supplying fresh air to interior.
2) Produce air convection as a heat radiator, reducing indoor temperature, increasing air fresh.
3) Reduce air conditioning load, increasing the cooling effect.
Model NO. | Neck Diameter (mm) | Air speed (m/s) | Air capacity (m/h) | Weight (kg) |
SY-100 | 100 | 3.4 | 280 | 1.2 |
SY-160 | 160 | 3.4 | 540 | 2.1 |
SY-200 | 200 | 3.4 | 860 | 3.0 |
SY-300 | 300 | 3.4 | 1280 | 3.5 |
SY-400 | 400 | 3.4 | 1680 | 4.5 |
SY-500 | 500 | 3.4 | 2520 | 6.0 |
SY-600 | 600 | 3.4 | 3600 | 8.0 |
SY-700 | 700 | 3.4 | 4600 | 12 |
SY-800 | 800 | 3.4 | 6500 | 13 |
SY-900 | 900 | 3.4 | 8200 | 14 |
SY-1000 | 1000 | 3.4 | 10600 | 15 |
SY-1100 | 1100 | 3.4 | 12800 | 20 |
SY-1200 | 1200 | 3.4 | 14800 | 22 |
Roof Ventilation Fan,Wind-driven Turbine Ventilator,Non Power Turbo Fan for Warehouse/Factory/Workshop :
Widely used in these places
1) Ware house;
2) Factories and workshops (such as paper mill, galvanized products producing factories,
painting factories);
3) Garage and other buildings which need air ventilate.
