HTF Fireproof Smoke Exhaust Axial Flow Fan with High Temperature Resistant Properties

Large Image : HTF Fireproof Smoke Exhaust Axial Flow Fan with High Temperature Resistant Properties

Product Details:

Place of Origin:	Shandong, China
Brand Name:	shuangyi
Certification:	ce

Payment & Shipping Terms:

Minimum Order Quantity:	1 PC
Price:	$680.00/sets
Packaging Details:	Standard export package: Plywood case

Contact Now

HTF Fireproof Smoke Exhaust Axial Flow Fan with High Temperature Resistant Properties

Description

Type:	Axial Flow Fan	Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C
Customized Support:	OEM, OBM	Electric Current Type:	AC
Mounting:	FREE STANDING	Blade Material:	Stainless Steel ,FRP
Voltage:	220-380V,50HZ	Warranty:	1 Year
After-sales Service Provided:	Video Technical Support	Product Name:	AC Axial Fan
Application:	Exhaust Ventilation	Material:	Steel/FRP
Keyword:	For Fire Fighting Smoke Exhaust	Advantage:	High Temperature Resistant
Diameter:	200-1200mm

HTF fireproof smoke exhaust fan

Product Description

HTF Fireproof Smoke Exhaust Axial Flow Fan with High Temperature Resistant Properties 0

1.Application

SY fire-fighting smoke exhaust fan is mainly used in high building, underground garage, subway, tunnel and other places for firefighting exhaust smoke when the building catches fire, thus to get longer time for people to escape. In daily time it can be used for ventilation also.

2.Features:

The motor of this fan is covered in the steel panel box to standby high temperature for a long time.According to GA211-1999 fire-fighting fan high temperature resistance test method, it can run more than 4 hours when the temperature reach 280°C. When the temperature of the medium reach 100°C, the fan can run more than 20 hours at least without damage.

3. Type:

Fire smoke exhaust fan is divided into horizontal, vertical and cabinet type 3 kinds; The vertical type is used for roof.

HTF Fireproof Smoke Exhaust Axial Flow Fan with High Temperature Resistant Properties 2

Technical Parameters:

machine Number	air flow capacity (m³/h)	static pressure(Pa)	Power(kW)
2F	600-725	65-45	0.025
2.5F	1000-1425	120-80	0.09
3F	1750-2450	175-100	0.18
3.5S	1000-1875	150-100	0.37
3.5F	2000-2625	300-250	0.37
4S	2000-2670	200-145	0.37
4F	3000-4490	400-260	0.75
4.5S	3000-4170	240-180	0.37
4.5F	4000-6000	500-350	1.1
5S	4000-5500	300-200	0.75
5F	5000-7900	700-450	2.2
6S	5000-9990	480-290	1.5
6F	8000-13900	1000-600	5.5
7S	8000-14900	625-400	3.0
8S	12000-23900	860-440	5.5

Sample Pictures:

HTF Fireproof Smoke Exhaust Axial Flow Fan with High Temperature Resistant Properties 4

HTF Fireproof Smoke Exhaust Axial Flow Fan with High Temperature Resistant Properties 7
